Mahlkonig DK27LVS / DK27LVH Industrial Grinder
Mahlkonig DK27LVS / DK27LVH Industrial Grinder
- Outstanding even grinding quality
- Wear-resistant premium burrs
- Very powerful three-phase motors with surface cooling and high starting torque
- Suitable for continuous operation
- Service-free, constantly greased bearings
- Two additional fans to cool the motor
- Ground material container (capacity 200 l)
Click here for Operating Instructions
Voltage // frequencies // phases:
208-220 V // 50 Hz // 3~ 208-220 V // 60 Hz // 3~
380-415 V // 50 Hz // 3~ 380-415 V // 60 Hz // 3~
- Idle speed: 980 rpm (50 Hz); 1160 rpm (60 Hz)
- Burr diameter: 180 mm / 5.11 in
Burr material:
- DK27 LVS, DK27 LVST: Fully hardened special steel
- DK27 LV, DK27 LVT: Fully hardened special cast steel
- DK27 LVHT, DK27 LVH: Tungsten Carbide
Grinding capacity - fine* kg / Std (ca.):
- DK27 LV: 230
- DK27 LVS: 280
- DK27 LVH: 260
Grinding capacity - medium* kg / h (ca.):
- DK27 LV: 250
- DK27 LVS: 300
- DK27 LVH: 280
Grinding capacity - turkish* kg / Std (ca.):
- DK27 LVT: 170
- DK27 LVST: 180
- DK27 LVHT: 220
- Hopper capacity : ca. 30 kg / 66.13 lb
- Max. nominal power: 5500 W
- Dimensions incl. base (w x h x d): 79 x 160 x 123 cm
-
Net weight incl. base:
DK27 LV, DK27 LVS, DK27 LVT, DK27 LVST: 155 kg
DK27 LVH, DK27 LVHT: 158 kg
- Dimensions of packing & gross weight: depends on individual version and equipment
- Dimensions Container (w x h x d): 69 x 70 x 79 cm
- Standard color: Grey structured
SPECIAL EQUIPMENT
- Burrs for grains or for other grinding goods
- Special burrs for espresso or for turkish fine grinding
- Additional ventilation
- Electronically controlled grind adjustment
- Electropneumatic gate for an controlled supply of material
- Customized color from RAL catalogue
*Depends on the grinding goods and the chosen degree of fineness.
All measured values under laboratory conditions. Other electric specifications available on request. Subject to change without prior notice.
